Security is a broad field, so we will cover a smattering of topics that are likely to be useful to at least many of you.

Passwords

The most obvious way to handle passwords in an application is to simply store them somewhere (in a database, perhaps) and when a user attempts to log in, look up the password that corresponds to the user and verify that it matches.

This actually works just fine, but it has some very unfortunate consequences in the event that the database where the passwords are stored is compromised since the attackers get immediate access to all user credentials. Now, you might think that this isn’t a big deal since, if the database has been compromised, the attackers already have access to every user’s data anyway, but, unfortunately, people tend to re-use passwords across applications. This means that a password stolen from an inconsequential application might give the attackers access to a user’s email or bank account.

To mitigate this issue, we hash passwords before they are stored. This means that we apply a one-way function to transform the password into a different value that can’t be easily converted back into the original password. To do this, we use a “hash function”. This is a function h(x) -> y with the property that there exists no (reasonable) function h'(y) -> x.

One such hash function is called SHA-256. This is the one we will use in our examples.

Hashing passwords before storing them goes a long way to fixing the problem described above, but attackers can still reverse a hash function, at least probabilistically, using a tool commonly called a Rainbow Table. This is, essentially, a table of pre-hashed passwords either randomly generated or known to be in common use. Once such a table has been computed, it is trivial (and very fast) to convert a hash back into the original password (assuming the hash exists in the table).

The prevent this, we apply what is known as a “salt” to each password before it is hashed. Essentially, we take the user’s password, add some random data to it to make it stronger, hash the salted password, and then store the hashed password along with the salt value in our database. See the pseudo-Python below.

def hash_password(pw):
    salt = random_salt()
    salted_pw = pw + salt
    hashed_pw = sha256(salted_pw)
    return (hashed_pw, salt)

Now, let’s assume that we use a single, randomly chosen, lower-case letter as the salt value. This means that an effective rainbow table must hash each password 26 times, once with each possible salt value. This is quite a bit more work, and makes the table take up quite a bit more space on disk. If we make our salt values four characters long and allow all alphanumeric characters then a rainbow table with a given level of effectiveness will be 62⁴ = 14, 776, 336 times as large. That’s already entirely impractical for a table that contains more than just a few potential passwords.

Example

Take a look the scripts below and play around with hashing various passwords, generating rainbow tables, and looking up passwords in those tables.

SQL Injection

SQL injection is a common attack used against applications that store their data in a SQL database. It works by tricking a program into inserting code into a SQL statement instead of just data.

For example, in the famous cartoon above, the child’s name contains SQL code that is designed in such a way that it is likely to be syntactically valid when directly interpolated into a SQL query, but when it is run it attempts to delete the database table called “Students”.

The reason this sort of thing works is that we build up SQL code inside of our programs, then execute that code on the fly. The same thing would be possible with ordinary programming languages if we created code on the fly. In fact, many languages have the ability to evaluate snippets of their own code, but doing so is generally considered a bad idea because it can leave a program open to similar injection attacks. For example, Python supports this through the eval function:

eval("print('hello')")

Typically, SQL injection is prevented by correctly parameterizing queries. Different database client libraries for different programming languages may use different syntax for doing this, but most provide similar capabilities. For exampe, the query below is vulnerable to injection:

cursor.execute("SELECT * FROM users WHERE name='%s'" % name)

On the other hand, this query is not, because it substitutes the name into the query using the SQL library as opposed to simple string interpolation:

cursor.execute("SELECT * FROM users WHERE name=?", (name,))

A good rule of thumb is to never include user input in code that will be run on the fly unless it has been properly escaped / sanitized. Also keep in mind that this isn’t something you want to try to do yourself because it is easy to forget an edge case and leave your program open to injection attacks.

Example

Take a look at user-lookup.py for an example. This script accepts a user name and a password and prints a secret word, specific to that user, if the password is correct.

The first time it is run it will create a database file called users.db. You can reset the database by deleting the file. You can also interact with the database directly using the sqlite3 tool, if you have it installed.

If you enter the wrong password, however, you’ll get back an error message instead of the super secret word.

Try running it for “George” as well (his password is “sosecure”). As you can see, George and Travis have different secrets.

What happened? Why did it produce that result? How did it give us George’s secret without the correct password?

Buffer Overruns

A buffer overrun occurs when a program reads memory beyond the end of an array. This is impossible to do in most languages, but it can happen in languages like C that allow direct access to memory and, in particular, pointer arithmetic.

Pointer arithmetic is basically what it sounds like. A pointer is just an address in memory, which means that it is an integer since “memory” is essentially just a linear array of bytes (see below).

In C, an integer can be used as a pointer, and a pointer can be used as an integer, they are essentially the same thing. Therefore, pointers can be added and subtracted. This means that if I have a pointer to a particular memory location, let’s say 0xFF56, I can add one to it and now I have a pointer to the memory location 0xFF57. Now, if I dereference this pointer, I get whatever data happens to be stored at 0xFF57.

In fact, this is essentially how arrays work in C. The syntax myArray[5] is actually just shorthand for something like:

*(myArray + 5)

As you might guess, then, an array variable in C is very similar to a pointer to the first element (the reality is a little more complicated, but it’s a reasonable approximation). However, this means that there is no way for the computer to know how long you expect a given array to be, it knows where the array starts and not much else.

Because of everything described above, it is possible to read beyond the end of an array. The result of doing so depends on what is (or was) stored adjacent to the array data. An attacker can use a buffer overrun bug to attempt to access sensitive data, like encryption keys.

Example

The file secrets.c contains a program that loads secrets and names into memory and then provides access to the names by index. For example, ./secrets 0 prints “George” because that is the first value stored in the names array. However, if we run ./secrets 2 we get a surprise. Instead of a name (or an error message), we get one of the secret values!

You can build the program by running gcc -o secrets secrets.c, assuming you have the GCC C compiler installed.
